TRACE & MEASURE

Capturing the old & making them new

Reviving the Past

With the help of newest technologies we scan, trace and model old buildings and drawings as a reliable setting stone for your project development.

Sub-Services:
  • Paper to CAD
  • Measuring & 3D-Scanning
  • Point Cloud to 3D/2D
  • Building Simulation BIM
  • Area & Vol. Calculation

Sub-Services in Detail

Paper to CAD

Converting your hand drawn or archive paper scans into Digital formats.

We convert your hand-drawn or archived documents into digital formats such as DWG, RVT, ArchiCAD, dxf, dgn, etc. for more information, see the technical specifications on the Service page.

After scanning and vectorizing your documents, we manually redraw the image into fully editable CAD formats.

Measuring & 3D-Scanning

We provide fast and accurate ways to measure your existing area.

Our team will prepare for you the most accurate as-built plans, sections and elevations, which will form the basis for a redesign of the building. We can also provide you documents about the damaged elements in the building.

Point Cloud to 3D/2D

We convert raw point-clouds into CAD files for your further editing.

Our team will accurately trace the raw point-cloud-data and make them into accurate CAD files in 2D or 3D in the shortest amount of time.

Building Simulation in BIM

Creating a BIM simulation based on your data for better collaboration

Based on the measurements, we produce an accurate 3D Modell in BIM so you can share and coordinate with all the specialist planners as fast and accurate as possible.

Area & Volume Calculation

Area & volume calculations based on the provided data

We can export the exact areas and volumes of your project into sheets and lists, which contains all required characteristic values based on DIN standards. (e.g. NRF, BGF, etc,).

Trace & Measure Projects

Tracing Building Plans

Trace & Measure

Year : 2020
Client : Construction Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : tracing drawing, existing building, nachzeichnen, floorplan, residential house

Loft Renovation

Trace & Measure

Year : 2020
Client : Construction Company
Type of project : Roof Extension
Keywords : roof extension, densification, residential house, repurposing building, interior planning

Digitalized Building Plans

Trace & Measure

Year : 2020
Client : Construction Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, existing building, redrawing, new floorplan, residential house

Digitalized Elevation

Trace & Measure

Year : 2020
Client : Construction Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, existing building, redrawing, new elevation, residential house

Building Section Tracing

Trace & Measure

Year : 2020
Client : Construction Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : tracing drawing, existing building, redrawing, elevation, residential house

Tracing Old Floor Plans

Trace & Measure

Year : 2018
Client : Architecture Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, memorial building, redrawing, construction drawing, old & new

Retracing Old Building Plan

Trace & Measure

Year : 2018
Client : Architecture Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, existing building, LP3-5, construction drawing, old & new

Renovation Loft Apartment

Trace & Measure

Year : 2020
Client : Construction Company
Type of project : Roof Extension
Keywords : roof extension, vertical enlargement, residential house, old drawings, furniture plan

Repurposing Existing Building

Trace & Measure

Year : 2018
Client : Architecture Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, existing building, LP3-5, construction drawing, old & new

Repurposing Existing Building

Trace & Measure

Year : 2019
Client : Architecture Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, existing building, LP3-5, construction drawing, old & new

Repurposing Existing Building

Trace & Measure

Year : 2019
Client : Architecture Company
Type of project : BIM Digitalization & 3D Modelling
Keywords : digitalized drawing, existing building, LP3-5, construction drawing, old & new

Technical Specs

Deliverable Outputs

CAD (DWG, RVT, PLN, PLA, 3DS, etc)
3D (3DS, Rhino, Vray, Revit, Archicad)
BIM (IFC, RVT, etc.)
PDF, JPG, PNG, etc.

Supported Softwares

Revit, Autocad, Archicad, Vectoroworks, Rhino, Microstation, Vray

Deliverable Languages

English, German
